Product Details:
|
| Name: | 6 Colors High Speed Automatic Flexo Label Printing Machinery | Usage: | Paper Printer |
|---|---|---|---|
| Automatic Grade: | Automatic | Type: | The Leading Manufacturer Of Automatic Label Flexo Printing Machine |
| Dimensions(l*w*h): | 4500*2200*2700mm | Gross Power: | 10.5kw |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Printing Speed: | 80m/min |
| Warranty: | 1 Year | Product Name: | 8 Colors Flexographic Printing Machine |
| Color: | Five Color | Printing Material: | Rolling Material Different Kinds |
| Printing Color: | 4/5/6 Colours | Application: | Revised Printing Is Avaible |
| Material: | #45 Seamless Steel Tube Or No.5 Series Aluminum | Plate Thickness: | 1.7mm 3.9mm 2.28mm |
| Highlight: | 80m/min Flexo Label Printing Machine,five color Flexo Label Printing Machine,6 Colors flexo printer |
||
Flexo Die Cutting and Printing Press Machine for label flexo printing
High Speed Label Flexo Printing Machine
Main Feature:
1. Adopt the anilox roller to spread ink.
2. Unwinding and rewinding are controlled by magnetism power brake, clutch. (or by
automatic tension controller of mitsubishi , made in Japan).
3. Printing unit adopt 360º for registration.
4. Each printing unit have one IR drier.
5. The rubber roller can break away from automatically while parking, and running at
a low speed, in order to avoid water being black to be dry.
6. The main motor is adopted the import stepless regulation of frequency conversion.
7. Unwinding, web guiding,printing,IR drying,varnishing(UV),laminating,rotary die cutting,discharging the waste and rewinding can be finished in one process.This is an ideal machine for printing factories to print many kinds of labels.
Main Technical Parameter:
| Model | YSJ-320 |
| Printing Speed | 50-60m/min |
| Printing Color | 4 colors |
| Max.Web Width | 320mm |
| Max. Printing Width | 320mm |
| Max. Feeding Diameter6 | 00mm |
| Max.Rewinder Diameter | 400mm |
| Printing Perimeter | Between 160~370mm |
| Registration Accuracy | ±0.1mm |
| Voltage | 380v |
| Dimension | 3000X1600X1300mm |
| Total Power | 20kw |
| Weight of Machine | About 2200kg |
