Nonwoven And PP Fabric Laminating Machine

Nonwoven And PP Fabric Laminating Machine
Nonwoven And PP Fabric Laminating Machine Nonwoven And PP Fabric Laminating Machine Nonwoven And PP Fabric Laminating Machine Nonwoven And PP Fabric Laminating Machine Nonwoven And PP Fabric Laminating Machine Nonwoven And PP Fabric Laminating Machine Nonwoven And PP Fabric Laminating Machine

Large Image :  Nonwoven And PP Fabric Laminating Machine

Product Details:
Place of Origin: RUIAN
Brand Name: haijing
Certification: CE
Model Number: HJ-500
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: 7
Packaging Details: WOODEN CASE
Delivery Time: 15
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 88

Nonwoven And PP Fabric Laminating Machine

Description
Condition: New Application: Customerised
Plastic Processed: LLDPE.LDPE.PE Etc Screw Design: Double-screw
After-sales Service Provided: Commissioning And Training Voltage: 380V 50HZ 3Phase(Customized)
Automatic Grade: Automatic Power(w): 78kw
Weight: 8T Dimension(l*w*h): 10*8*3M
Warranty: More Than 5 Years Processing Type: Extruding Machine
Highlight:

PP fabric laminating machine

,

Nonwoven fabric laminating machine

,

Double screw pp woven fabric lamination machine

Nonwoven and PP Nonwoven Fabric Laminating Machine Price with PP Ldep and Lldep





Product Description

Nonwoven and PP Nonwoven Fabric Laminating Machine Price with PP Ldep and Lldep



Nonwoven and PP Nonwoven Fabric Laminating Machine Price with PP Ldep and Lldep
Nonwoven and PP Nonwoven Fabric Laminating Machine Price with PP Ldep and Lldep
Nonwoven and PP Nonwoven Fabric Laminating Machine Price with PP Ldep and Lldep



Product Description:

The laminating machine use Grade material LDPE, LLDPE, PP and so on as raw materials, which is specifically designed for online single-sided laminating of non-woven fabrics, woven bags and other products. In addition, it can also be used for paper base products.



Model

M1300/80



Screw diameter φ80 mm
Length diameter ratio of screw 33:1
Width of finished product 600-1200MM
Film thickness 0.01-0.10MM
Mechanical design line speed 120M/MIN
Maximum extrusion capacity 150KG/H
Main motor power 30KW
Total power 77KW
Main unwinding diameter ≤φ1200 MM
Winding diameter ≤φ1200 MM
2nd unwinding diameter ≤φ500 MM
weight 6T
Dimensions 7400*7000*3200MM
Power source 380V/3P/4L/50HZ

Machine Highlight:

1. The machine can do stable coating at a high speed of 80-120M/Min.
2. Automatic Tension and EPC, so that the equipment has a higher coating precision. Then will reduce Labor cost.
3. Special Custermized Options, allow clients to modify what is needed. such as adding the return racks so that double-sided coating can be realized only with a single die, meanwhile the thickness of the double-sided coating can be consistent.


Equipment production principle:

The raw material of plastic pellets is heated, plasticized and extruded by the extruder. Pressurized and plasticized by static mixer, extruded by T-die head, internal plugging die head adjusts the coating width without stopping the machine, and does not change the uniformity of the discharge thickness

The main feeder feeds, corona, enters the laminating machine, laminating and cooling.

The winding machine is equipped with automatic tension control, and the pressure is controlled by precision pressure regulating valves at both ends of the air expansion shaft to ensure stable winding. Under normal circumstances, the winder changes the rolls at the same time after the material is changed to ensure that one joint has one roll of film.



Nonwoven and PP Nonwoven Fabric Laminating Machine Price with PP Ldep and Lldep
Nonwoven and PP Nonwoven Fabric Laminating Machine Price with PP Ldep and Lldep
Nonwoven and PP Nonwoven Fabric Laminating Machine Price with PP Ldep and Lldep
