Film blowing machine

This film blowing machine is used for producing plastic packaging film.

Model		55-1100	60-1300	65-1600
Suitable Material		HDPE,LDPE,LLDPE
Film Width		500-1000mm	600-1200mm	1000-1500mm
Film Thickness		0.01-0.15mm
Max.Output	HD	120kg/h	150kg/h	190kg/h
	LD	150kg/h	180kg/h	220kg/h
Screw Diameter		Φ55	Φ60	Φ65
Screw L/D Lenth		30:1
Cylinder Cooling		370w*3		370w*4
Main Motor		22kw	30kw	37kw
Average Power Consume		25kw	35kw	60kw
Die Head		220mm	250mm	320mm
Air Blower		7.5kw	11kw
Roller Width		1100mm	1300mm	1600mm
Effective Width		1000mm	1200mm	1500mm
Take-up Speed		10-120m/min
Take-up Motor		1.5kw		2.2kw
Winding Type		PLC Automatic Roll Change
Winding Speed		10-120m/min
Power Supply		380V,50HZ,3PHASE
Outline Dimension(L*W*H)		6.5*3.2*6.8m	7*3.5*6.8m	7*4*7.5m
Weight		3.5t	4.5t	5t

Applications



Film blowing machines are core equipment for producing plastic films, and their applications vary significantly across countries due to industrial structure, agricultural demand, regulatory policies, and economic development levels. Below is a detailed analysis by region and country:



1. Asia-Pacific (Largest Market, Diverse Applications)

China

• Food Packaging (39.2% of total consumption): High-barrier films for fresh produce, frozen foods, snacks, and vacuum packaging; shopping bags and courier bags.
• Agriculture (21.5%): Greenhouse films, mulch films (biodegradable), silage films, and pond liners.
• Industrial & Medical: Electronic anti-static films, chemical liners, building geomembranes, and sterile medical packaging films.
• High-end: 5–9 layer co-extrusion lines for lithium-ion battery separators and high-barrier food packaging.

Southeast Asia (Vietnam, Indonesia, Thailand, Philippines)

• Food & Consumer Packaging: 3–5 layer machines for flexible packaging, shrink films, and cosmetic bags.
• Agriculture: Mulch and greenhouse films for tropical crops.
• Industrial: Wrapping films for logistics and construction protection.
• Trend: Rapid growth in high-speed lines due to “Make in Indonesia” and export-oriented manufacturing.

India

• Food & Retail: Shopping bags, packaging for spices, snacks, and dairy.
• Agriculture: Large-scale mulch and greenhouse films.
• Policy: “Make in India” subsidies drive upgrades to high-speed, energy-saving machines.

Bangladesh

• Packaging & Textiles: POF shrink films, LDPE bags for garments and food.
• Growing: 5-layer lines for export-oriented packaging.

2. North America (High Automation, High Value)

United States

• Food & Beverage: High-barrier films for ready meals, fresh produce, and frozen foods.
• Industrial & Logistics: Stretch hood films, heavy-duty wrapping films.
• Medical: Sterile packaging films and IV bag films.
• Tech Focus: IoT-enabled, high-speed lines with low scrap rates (15–20% reduction) and rapid changeovers.

Canada

• Agriculture: Silage films, greenhouse films for cold climates.
• Packaging: Food and industrial films for domestic and US export.

Mexico

• Packaging for US-bound goods: Flexible films for food, electronics, and automotive parts.
• Agriculture: Mulch and greenhouse films.

3. Europe (Sustainability-Driven)

Germany, Italy, France

• High-End Packaging: Multi-layer barrier films for premium food and cosmetics.
• Sustainability: Machines optimized for recycled resins (rPE, rPP) to meet EU Single-Use Plastics Directive.
• Agriculture: Silage films, greenhouse films, and biodegradable mulch films.

Eastern Europe (Bulgaria, Poland)

• General Packaging: LDPE bags, shrink films, and industrial liners.
• Growing: 3-layer co-extrusion lines for food packaging.

4. Latin America

Brazil

• Agriculture (Dominant): 5-layer lines for silage films, greenhouse films, and mulch films.
• Packaging: LDPE films for food and consumer goods.

Argentina, Chile, Peru

• Agriculture: Greenhouse and mulch films for high-value crops.
• Packaging: Basic bags and wrapping films.

5. Middle East & Africa

Middle East (Saudi Arabia, UAE, Jordan)

• Hygiene & Packaging: Diaper and tissue outer packaging, food flexible packaging.
• Construction: Geomembranes and protective films.
• Petrochemical Link: Abundant raw materials support local film production.

Africa (Kenya, Nigeria, Egypt, South Africa)

• Basic Packaging: LDPE bags, shrink films, and shopping bags.
• Agriculture: Mulch and greenhouse films for smallholder farming.
• Growth: Rising urbanization and retail expansion drive demand for entry-level to mid-range machines.
•



Region	Dominant Applications	Key Machine Types	Market Drivers
Asia-Pacific	Food packaging, agriculture, industrial	3–9 layer co-extrusion, high-speed	Manufacturing growth, urbanization, exports
North America	High-barrier food, medical, industrial	5-layer, IoT-integrated, high-speed	Automation, reshoring, quality standards
Europe	Sustainable packaging, premium food, agriculture	Recycled resin-compatible, multi-layer	EU regulations, sustainability goals
Latin America	Agriculture, basic packaging	3–5 layer, mono-layer	Agricultural expansion, local consumption
MEA	Hygiene, construction, basic packaging	Mono-layer, 3-layer	Urbanization, retail growth, local manufacturing

---



Would you like me to condense this into a 1-page English market summary for your sales or business development use?



Contact HAIJING

Q1:Can you provide installation and commissioning services for the machine?
A1:Yes, we not only help our customers with the installation service, but also assist our customers in successful operation. Customers can use their own formulas, and we can also provide some free film formulas for novice customers.

Q2: How about after-sales service? How long is the machine warranty

A2: Once you buy our machine, we guarantee lifetime after-sale
service, you can call us or send us an email to ask any questions about the machine. Three-year warranty for the five parts of the film blowing machine (motor, inverter, gear box, blower, die head).



Q3: Where is your factory? How can I visit there? Do you support online factory inspection?
A3:Our factory is located in RUIAN City, Zhejiang Province, China, about one hour from Shanghai by air. Warmly welcome domestic and foreign customers to visit us, and support 3D online factory inspection.



Q4:Does your factory need agents? What are the thresholds?

A4:We need to recruit agents, welcome to inquire for more details.

Q5:How long is your delivery time and how many machines can you produce per month?

A5:Normally delivered within 30-60 days.We can produce up to one hundred machines per month.



Q6:How long can your machine work continuously?

A6:Our machines can work 24 hours a day without stopping, which not only increases production but also saves energy.

Product Description:

The Film Extruder Machine is an advanced and highly efficient piece of equipment designed specifically for the production of high-quality plastic films. This machine is widely recognized in the industry for its robust construction, precision control, and versatile functionality, making it an ideal choice for manufacturers looking to optimize their plastic film production processes. Equipped with a state-of-the-art PLC control system with a touch screen interface, the Film Extruder Machine offers users an intuitive and user-friendly experience, allowing for easy monitoring and precise adjustments throughout the extrusion process.

One of the standout features of this Film Extruder Machine is its powerful main motor, available in two specifications: 7.5 kW and 11 kW. These motors provide the necessary torque and speed to ensure consistent and smooth extrusion, accommodating various production demands. Both motor options are sourced from reputable brands, including WANNAN, ensuring reliability, efficiency, and long service life. The combination of these high-quality motors and the advanced control system significantly enhances the machine’s operational stability and performance.

The machine is engineered to handle film thicknesses ranging from 0.004 mm to 0.1 mm, allowing manufacturers to produce films suitable for a wide range of applications, from ultra-thin packaging films to thicker, more durable plastic sheets. This flexibility is essential for businesses that require adaptability in their production lines to meet diverse market needs. Additionally, the Film Extruder Machine features dual screws with diameters of either 55mm*2 or 65mm*2 mm, which play a critical role in ensuring uniform melting and mixing of the raw materials. The twin-screw configuration enhances the machine’s ability to process various types of polymers efficiently, including recycled materials.

In the context of sustainability and cost-effectiveness, the Film Extruder Machine also functions excellently as a pp recycle machine. It is capable of processing polypropylene (PP) recycled pellets, turning waste plastic materials into valuable film products. This capability not only reduces environmental impact but also helps manufacturers lower raw material costs by utilizing recycled plastics. The machine’s compatibility with recycled PP materials underscores its role in promoting eco-friendly manufacturing practices within the plastic industry.

Moreover, this Film Extruder Machine is often utilized as part of a broader plastic processing setup that includes plastic pelletizing machines. When integrated with pelletizing units, the system allows for the efficient transformation of plastic waste into uniform pellets, which can then be fed back into the extruder for film production. This seamless integration supports a closed-loop recycling process, enhancing material utilization and minimizing waste. The synergy between the Film Rolling Extruder Machine and plastic pelletizing machines is vital for modern plastic manufacturers striving to achieve sustainability goals without compromising productivity.

Designed with precision engineering and high-quality components, the Film Extruder Machine guarantees consistent output and excellent film quality. Its robust construction ensures durability and long-term operation under demanding production environments. The inclusion of premium motors from WANNAN further assures that the machine operates smoothly with minimal downtime, contributing to higher overall efficiency and profitability.

In summary, the Film Extruder Machine is a versatile, reliable, and technologically advanced solution for plastic film production. Its PLC with touch screen control system enables easy operation and precise process control, while the powerful 7.5 kW or 11 kW motors deliver consistent performance. The machine’s ability to produce films with thicknesses ranging from 0.004 mm to 0.1 mm, combined with dual screw diameters of 55mm*2 or 65mm*2 mm, makes it adaptable to a wide variety of production requirements. Additionally, its function as a pp recycle machine and its compatibility with plastic pelletizing machines position it as an essential component in sustainable plastic manufacturing workflows. For businesses seeking a high-quality Film Rolling Extruder Machine that balances efficiency, flexibility, and environmental responsibility, this Film Extruder Machine represents an excellent investment.

Applications:

The Haijing Film Extruder Machine, model HJ-330 450, is an advanced Plastic Film Extrusion Machine designed for a variety of industrial applications. Originating from China, this versatile machine is engineered to handle PVC powder as raw material with an impressive extrusion capacity ranging from 100 to 500 Kg/h. Its robust construction features a screw diameter between 45 to 90 mm, enabling efficient and consistent production of high-quality plastic films. Equipped with reliable SIEMENS and WANNAN motors, the Haijing machine ensures stable operation and long-term durability, making it ideal for continuous manufacturing processes.

One of the primary application occasions for the Haijing Film Extruder Machine is in the production of flexible packaging materials. As a Flexible Film Extrusion System, it is widely used in industries such as food packaging, agricultural films, and industrial wrapping solutions. The machine’s ability to process PVC powder into uniform plastic films makes it suitable for creating products that require excellent clarity, strength, and flexibility. Manufacturers looking to produce customized film colors can benefit from the machine's adaptable color options available as per request.

Additionally, the Haijing Film Extruder Machine plays a significant role in the plastic recycling sector. When integrated into a plastic recycling pelletizing line, it contributes to the reprocessing of plastic waste into reusable pellets and films. This enhances sustainability efforts by enabling the conversion of recycled PVC materials into high-quality films for secondary applications. The machine’s efficient extrusion capacity and reliable motor system support high-volume recycling operations, making it a valuable asset in reducing plastic waste and promoting circular economy practices.

Overall, the Haijing HJ-330 450 Film Extruder Machine is suitable for a wide range of scenarios, from new plastic film production to the recycling and repurposing of plastic materials. Its combination of advanced technology, robust design, and versatile functionality ensures it meets the demands of diverse industries seeking efficient and reliable plastic film extrusion solutions.

Packing and Shipping:

The Film Extruder Machine is carefully packaged to ensure it arrives in perfect condition.

The machine is securely wrapped with protective materials and placed inside a sturdy wooden crate to prevent any damage during transit.

For shipping, we offer multiple options including sea freight, air freight, and land transportation, tailored to meet the customer's requirements. All shipments are handled by experienced logistics partners to guarantee timely and safe delivery.

Before dispatch, the Film Extruder Machine undergoes thorough inspection and testing to ensure it meets quality standards. Detailed documentation, including user manuals and warranty information, is included in the package.

We also provide assistance with customs clearance and export procedures to facilitate a smooth shipping process.

FAQ:

Q1: What is the brand and model number of the Film Extruder Machine?

A1: The Film Extruder Machine is manufactured by Haijing, and the model number is HJ-330 450.

Q2: Where is the Haijing Film Extruder Machine made?

A2: The Haijing Film Extruder Machine is made in China.

Q3: What types of films can the HJ-330 450 extrude?

A3: The HJ-330 450 model is designed to extrude various types of plastic films, including polyethylene (PE) and other common plastic materials used in packaging and agricultural applications.

Q4: What is the production capacity of the Haijing HJ-330 450 Film Extruder Machine?

A4: The production capacity depends on material and settings, but typically the HJ-330 450 can produce a high volume of plastic film efficiently, suitable for medium to large scale production needs.

Q5: What are the main features of the Haijing HJ-330 450 Film Extruder Machine?

A5: The Haijing HJ-330 450 features high precision extrusion, energy efficiency, easy operation, and stable performance, making it ideal for producing high-quality plastic films.
