Product Details:
|
| Usage: | Paper Printer | Automatic Grade: | Automatic |
|---|---|---|---|
| Type: | Flexographic Printer | Dimensions(l*w*h): | 4500*2200*2700mm |
| Voltage: | 220V/380V/Customize | Condition: | New |
| Weight: | 5000kg | Gross Power: | 30kw |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Printing Speed: | 80m/min |
| Warranty: | 1 Year | ||
| High Light: | Paper Film Flexo Label Printing Machine,Flexo Label Printing Machine 80m/Min,220V flexographic press machine |
||
High Speed Label Flexo Printing Machine
Main Feature:
1. Adopt the anilox roller to spread ink.
2. Unwinding and rewinding are controlled by magnetism power brake, clutch. (or by
automatic tension controller of mitsubishi , made in Japan).
3. Printing unit adopt 360º for registration.
4. Each printing unit have one IR drier.
5. The rubber roller can break away from automatically while parking, and running at
a low speed, in order to avoid water being black to be dry.
6. The main motor is adopted the import stepless regulation of frequency conversion.
7. Unwinding, web guiding,printing,IR drying,varnishing(UV),laminating,rotary die cutting,discharging the waste and rewinding can be finished in one process.This is an ideal machine for printing factories to print many kinds of labels.
Main Technical Parameter:
| Model | HJ-320 |
| Printing Speed | 50-60m/min |
| Printing Color | 4 colors |
| Max.Web Width | 320mm |
| Max. Printing Width | 320mm |
| Max. Feeding Diameter6 | 00mm |
| Max.Rewinder Diameter | 400mm |
| Printing Perimeter | Between 160~370mm |
| Registration Accuracy | ±0.1mm |
| Voltage | 380v |
| Dimension | 3000X1600X1300mm |
| Total Power | 20kw |
| Weight of Machine | About 2200kg |
Flexo Printing Machine with Die Cutting System Mini Sticker Label Flexo Printing Machine
Main equipments of 1-6 colour Narrow Web Bag Flexo label printer Printing Machine:
1. The main motor is equipped with a frequency conversion stepless speed regulation device imported from Japan. This device can reduce mechanical shock and power consumption, thus prolonging machine’s lifespan and reducing operating cost.
2. Winding and unwinding are controlled by magnetic brake and clutch.
3. Unwind tension controller is Japan’s Mitsubishi automatic tension controller. This guarantees stable and reliable winding and unwinding.
4. The anilox roll has strong resistance to abrasion and corrosion, thus having a long lifespan. This frees users from the troubling of regularly replacing the rolls. When the printing of one color and the 360°circular register regulation is adopted. Each printing unit can be taken apart and used independently.
5. It is equipped with a drying device which enables the ink to rapidly condense to avoid ink blurring or shedding and brings convenience to the cutting operation of the printed products.
6. Customers can choose to install infrared or UV drying device. They can also specify the color of the equipment.
7. The flexographic printing machine is equipped with a deviation correction sensor which can automatically control the material feeding device and make the printing accurate and stable.
