Product Details:
|
| Weight: | 2000kg | Warranty: | One Year |
|---|---|---|---|
| Machine Type: | Bag Forming Machine | Voltage: | 380V/220V |
| Material: | Paper | Dimension(l*w*h): | 6500*2000*1900mm |
| Highlight: | 14oz paper cone cup machine,Straight Brim paper cone cup machine,14oz paper cone cup production line |
||
The paper cone cup machine (Straight Brim) can be used for the production of snack and drinking cones of coated, non-coated or dry-waxed paper. It offers the highest production speed of up to 220 pieces per minute. The machine covers an area of 4M × 1.65 M and weighs approximately 2 tons.
Experienced manufacturer of paper cone cup machine based in China. we are provided with convenient transportation which can help you reduce the international transportation costs. If you would like to know more about any of our products, please turn to the corresponding pages of ice cream paper cone machine, automatic paper punching machine, carton erecting machine, aluminum foil paper, etc. We welcome you to contact us and we look forward to working with you.
| Power | 380V/50Hz |
| Air Pressure | 0.6MPa (Dry and clean compressed air) |
| The total Power | 12KW |
| Highest Production Speed | 180 PCS/min |
| Covering Area | 4.0M*1.65M |
| Packing | 2250mm*1760mm*1960mm, N. W.: 1800KG, G. W.: 1850KG 1250mm*1200mm*1060mm, N. W.: 250KG, G. W.: 300KG |
| Materials | Coated Paper 90-120GSM, White Kraft Paper and Wax Paper 90-150GSM. |
| Machine type | HJ |
| Specification | 1.5-14oz |
| Height | 70-145mm |
| Wall angle | 40° |
| Maximum web width | 180mm |
| Max. Reel diameter | 1200mm |
Paper Cone Cup Sample ( Free provide if needs )
