Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation

Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation
Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation
Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation

Large Image :  Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation

Product Details:
Place of Origin: Wenzhou Ruian Haijing Machinery
Brand Name: HJ
Certification: Ce
Model Number: HJ-1100
Payment & Shipping Terms:
Minimum Order Quantity: 1tower
Price: 2000dollar/tower
Packaging Details: Container packaging
Delivery Time: 4work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1tower/20todays
Contact Now

Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation

Description
Dimensions Inside The Board And Frame: 1100*800 Working Speed: 20±2
Maximum Blade Length: ＜30m Power: 4KW
Net Weight: 3900kg Overall Dimensions: 2050*1950*1700
Highlight:

Alloy Steel Sliding Bearings Emboss Machine

,

4 KW Alloy Emboss Machine

,

Welded Indentation Emboss Steel Machine

Configuration table of flat indentation machine (model HJ1100)

Technical parameters:

1. Size inside the frame: 1100 * 800

2. Working speed: 20 ± 2

3. Maximum blade length: ＜ 30m

4. Motor power: 4KW

5. Net weight: 3900kg

6. External dimensions: 2050 * 1950 * 1700

1. The casting of the machine is HT200 Gray iron, which is annealed. It can make the castings of the machine (including the body, press frame, etc.) less prone to deformation and fracture.

2. The spindle of the machine is made of 45 # steel.

3. The main gears of the machine are also made of four phosphorus chromium steel, which is then quenched and tempered.

4. The guide rail lining of the machine is made of 38 chromium molybdenum aluminum, which is then nitrided. It greatly enhances its hardness and is less prone to wear and tear. It can keep the pressure of the machine in balance and not easily change.

5. The bearings of the machine are made of Wafangdian bearings.

6. The machine adopts a centralized refueling lubrication system, which can better ensure the smoothness of the oil circuit. Make the maintenance and refueling of the machine more convenient.

7. The connecting rod shaft sleeve of the machine is made of pure copper sleeve. Make the machine more precise.

The key and main components of the above machines will not be explained separately.
Main structural features:
1.Sliding bearings are mnade of high quality alloy cooper, thus to get effect of anti- friction and shake reducing.
2. Flywheel is with big moment of force and large pressure.
3. High strength due to one piece casting by using top-rankingmaterial for rmachine body.
4. Single plate electromagnetic clutch is sensitive aind reliable.
5. With functions of single , coontinuous and opening dwelll operation, dwell range is adjuustable.
6. Operating position is reasonably arranged, moving-bedlcan be opened to its optimum.
7. Reliable safety protectioon system.
Model Max.Rule Area Working Speed Max.Rule Length Motor Power Weight Overall Deminsion
HJ-1200 1200*830mm 20+-2(strokes/min) <32M 5.5KW 4500kg 2050*2150*1900mm
HJ-1100 1100*800mm 20+-2(strokes/min) <30M 4KW 4200kg 2000*1950*1700mm
HJ-1040 1040*720mm 22+-2(strokes/min) <28M 4KW 3200kg 1850*1800*1700mm
Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation 0Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation 1Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation 2Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation 3Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation 4Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation 5Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation 6Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation 7Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation 8Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation 9Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation 10Alloy Steel Sliding Bearings Emboss Machine HJ1100 4KW Motor Welded Indentation 11
