Product Details:
|
| Automatic Grade: | Automatic | Weight: | 3500kg |
|---|---|---|---|
| Type: | Flexographic Printer | Usage: | Paper Printer |
| Dimensions(l*w*h): | 3900*1660*2950mm | Voltage: | 220V/380V |
| Condition: | New | Gross Power: | 12.5KW |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Warranty: | More Than 5 Years |
| Printing Speed: | 50m/min,1500-3500p/h | Color: | Customer Made |
| Name: | Non Woven Fabric Flexo Printing Machine | Material: | Plastic Film/Nonwoven Fabrics,aluminum Foil.,Stainless Steel,paper,plastic Film |
| Product Name: | Six-Colour Flexographic Printing Machine | Application: | Shopping Bag |
| Machine Type: | Stack Type Flexo Printing Machine | Plate: | Static Balance And Dynamic Balance Processing |
| Plate Thickness: | 4-6mm | ||
| High Light: | haijing High Speed 4 colour flexo printing machine,haijing 220V 4 colour flexo printing machine,haijing 380V ci flexo printing machine |
||
High Speed 4 Color Central Drum Type Flexo Printing Machine for Plastic Film Gearless Sleeve Box film Central Drum Impre
4 Color Flexo Printing Machine (CE)
Main Technical Parameter
| Model | CI4-600E | CI4-800E | CI4-1000E | CI4-1200E |
| Color | 4 colors | 4 colors | 4 colors | 4 colors |
| Max. Web width | 600mm | 800mm | 1000mm | 1200mm |
| Max. printing width | 600mm | 800mm | 100mm | 1200mm |
| Printing material | Baby diaper, Heat shrinkable ,BOPP, PET, PE, NY. PE breathable film Etc. | |||
| Printing length (repeat) | 350-800mm | |||
| Max. Mechanical speed | 250m/min | |||
| Max. Printing speed | 200m/min | |||
| Max. Unwind/ rewind Dia. | Φ800mm/Φ1000mm | |||
| Register precision | Longitude:±0.15mm; Transverse:±0.15mm | |||
| Press power | Mechanic control | |||
| Printing way | Full width on one side | |||
| Printing plate lifting system | Automatic Hydraulic cylinder control printing roll up and down | |||
| Drying model | Electric heating | |||
| Printing plate thickness | Photopolymer plate 1.7mm or 1.14mm ( As customer requirement) | |||
