Product Details:
|
| Automatic Grade: | Automatic | Weight: | 5500 KG |
|---|---|---|---|
| Type: | Flexographic Printer | Usage: | Paper Printer |
| Dimensions(l*w*h): | L4500xW2300xH2950MM | Voltage: | 220V/380V/Customize |
| Condition: | New | Gross Power: | 50HZ |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Warranty: | More Than 5 Years |
| Printing Speed: | 1500-3500p/h | Color: | Eight Colors |
| Name: | Non Woven Fabric Flexo Printing Machine | Material: | Plastic Film/Nonwoven Fabrics |
| Product Name: | Six-Colour Flexographic Printing Machine | Application: | Revised Printing Is Avaible |
| Machine Type: | Stack Type Flexo Printing Machine | Plate: | Static Balance And Dynamic Balance Processing |
| Plate Thickness: | 2.38/3.94mm | ||
| High Light: | 6 Color ci flexo machine,380V ci flexo machine,220V flexo plastic printing machine |
||
6 Color Economic Ci Type Flexographic Printing Machine for Plastic, Paper High Speed 4 Color Central Drum Type Flexo
Feature:
1.Method: Central impression for better color registration. With the central impression configuration, the printed material is supported by the cylinder, and greatly improving color registration, especially with extensible materials.
2.Structure: Wherever possible, parts are communized for availability and wear-resisting design.
3.Dryer: Hot wind dryer, automatic temperature controller, and separated heat source.
4.Transmission: Siemens Motor, and encoder buttons are placed on both control chassis and body for operations convenience.
5.Rewind: Micro Decelerate Motor, drive Magnetic Powder and Clutch, with PLC control tension stability.
6.Gearing of Printing cylinder: repeat length is 5MM.
Technical Parameter :
| Model | HJ6-600 | HJ6-800 | HJ6-1000 | CI6-1200 | HJ6-1400 | HJI6-1600 |
| Max. Material width | 650mm | 850mm | 1050mm | 1250mm | 1450mm | 1650mm |
| Max. Printing width | 560mm | 760mm | 960mm | 1160mm | 1360mm | 1560mm |
| Printing color | 6+0 | |||||
| Printing length | 11.8''-31.4''(300-800mm) | |||||
| Printing cylinder way | Pneumatic control up and down | |||||
| Drive type | Big center Roller drive | |||||
| Mechanical speed | 150m/min | |||||
| Printing speed | 10-130m/min | |||||
| Anilox roller | Ceramic anilox roller 6pcs: Shanghai murata brand 200-800LPI Open type doctor blade 3pcs Chamber doctor blade 3pcs with two diaphragm pump |
|||||
| Tension system | Automatic tension controller with magnetic powder brake | |||||
| EPC | Web guide 1pcs | |||||
| Register precision | Longitudinal:±0.15mm crosswise:±0.15mm; | |||||
| Color register | By manual | |||||
| Unwind/rewind dia. | Φ1000mm/Φ1200mm | |||||
| Unwind/rewind way | Center unwind; Center rewind | |||||
| Material holder | Air shaft 3'', 2pcs | |||||
| Dry system | Electric heating | |||||
| PLC human touch screen | 1set, Taiwan delta brand | |||||
| Image inspect system | 1set, China famous kesai branad | |||||
| Machine power | 40KW | 44KW | 50KW | 54KW | 60KW | 65kw |
| Machine size (L x W x H) |
6.5×2.2×3.5m | 6.5×2.4×3.5m | 6.5×2.6×3.5m | 6.5×2.8×3.5m | 6.5×3×3.5m | 6.5×3.m×3.5m |
Optional parts: need extra cost
1. Various size of printing cylinder
2. chamber doctor blade
3. Half width-double sides printing device
4. Color register: by motorized ( left and right, up and down)
5. Double unwinder /rewinder system
6. Automatic loading
7. Automatic unloading
8. shaftless for unwind
9. Servo motor for unwind/rewind
10. crane
11. plate mounting machine
12. ultrasonic anilox roller cleaning machine
Toolbox 1pcs: spare part for free
| 1 | Tool box | 1set |
| 2 | Phillip screwdriver | 1pcs |
| 3 | Slotted screwdriver | 1pcs |
| 4 | Inner Hexgam Spanner | 1set |
| 5 | Oil gun | 1pcs |
Machine picture:
Match chamber doctor blade & PLC & camera
200m/min speed central drum ( CI type) flexo printing machine:
Sample:
ABOUT COMPANY:
a professional Of Kinds Printing Machines and related products .
We Have Many Kinds Printing Machines, Normal Speed Printing Machine 50 meter/min , Middle Speed 80Meter/min and higher speed Printing Machine which Over 120M/MIN, 160M/MIN, 200M/MIN
Machine size: Standard size: 600-1200mm
also we can make 1500mm, 1800m,2000mm, 2400mm , 3200mm .
Offer your details , Make machines only belongs to you .
1) Good Quality , Well and timely Service, Competitive Price
2) Certificate : CE Certificate
3) One Year Warranty For Free, Long Life Service .
4) Tension Controller, EPC ,Ceramic Rollers,Doctor Blade.
5)Taiwan Motors
