Product Details:
|
| Dimension(l*w*h): | 15000*3000*2500 | Bag Type: | Shopping Bag,Fruit Bag,T-shirt Bag,Other,vest Bags And Flat-opening Bags |
|---|---|---|---|
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas,Video Technical Support,Free Spare Parts,Field Maintenance And Repair Service,Field Installation | Name: | Automatic Paper Bag Making Machine,high Speed Plastic Bag Making Machine,mango Bag Making Machine |
| Type: | Fully Automatic Paper Bag Making Machine,Paper Bag Forming Machine | Application: | Square Bottom Paper Bag Making Machine,Supermarket,paper Packaging,Fruit Bags,Fully Automatic Paper Bag Making Machine |
| Product Name: | Full Automatic Flat Square Bottom Paper Bag Making Machine,STD-930 Hand-bag Pasting Machine,mango Bag Machine | Bag Width: | 80-250 |
| Highlight: | Cement Paper Bag Making Machine,Paper Bag Making Machine 250mm,Automatic PLC Paper Bag Machine |
||
The latest design machine make kraft paper bag for cement
The latest design machine make kraft paper bag for cement
The tuber machine is with light, electricity, gas three-in-one high automatic production technology. It has the characteristics like human-computer interface adjustment (Touch screen control), Frequency control, Precision Servo, PLC programming control systems, Automatic counting, Alarming system for security production etc.
The main parameters
|
1).Production capacity
|
Stable speed --60-100 pcs bag plain end bag tubes / min (the production speed is determined by the bag length and the quality of paper) |
| 2).Finished bag width | 380-630mm, free adjustment (Customized in bag size range) |
| 3).Bag side | Straight or folding side (“M” side gusset width size: 0-140mm) |
| 4).Bag length |
Free adjusted, PLC servo control the cutting length. Touch screen freely set the length |
| 5).Max layers | 4 |
| 6).Total Power | 20 KW |
| 7).Machine Dimensions | Length13m×Width2.4 m× Height 2.1m |
| 8).Machine weight | 13 ton(around) |
| 9).Operators: | 1- 2 |
| 10) .Power supply condition | 380V,50HZ,3P ,4 L,AC |
| 11).Control method | DELTA servo control system |
| 12).Outer layer Material | Kraft Paper (White, brown, yellow, pink etc.) |
| 13).Inner layer Material | Kraft Paper, PE film, Metal Foil Paper |
| 14). Kraft paper gram weight | 75-120 gsm |
| 15).Max diameter of paper reel | 1200mm |
| 16).Max paper width | 1250mm |
| 17).Paper reel inner core diameter | 76mm |
| 18). Cutting bags counting | Automatic photoelectric counting |
The main Machine Configuration:
| Standard configuration | Quantity(set) |
| Paper roll feeding rack | 4 |
| Central glue unit | 1 |
| Tube Shaping unit | 1 |
| Host unit(Cutting unit) | 1 |
| Electric cabinet | 1 |
Semi-Autoamtic Pasting Auxiliary Equipment
1.Machine dimension:4.5m*1.2m*1.4m
2.Power:around 1KW
3.Controll method:frequency control
4.Electric condition:220V
5.Operators suggestion for assisting:2-3 persons/set
6.Production efficiency:Determined by manually speed
7.Remark:This equipment is for assisting manually pasting
Small Valve Tube Machine
It is a micro tuber machine to make the valve tubes
1.Operator:1-2
2. Variable frequency driver
3. Frequency conversion motor: 3.5KW;
4. Intermediate relay HH52P AC200V;
5. AC contactor coil AC220V 60A;Schneider
6. Button:Schneider;
7. Indicator light (green); Schneider
8. Solid state relay (single phase 1.5KW);
9. Alarm lamp (sound, light);
10. Proximity switch: 2
11. Switching power supply : DC24V 2.1A
12. Equipment weight: ≈1.6t
13. Overall dimension: L 3.7m*W 1.2m*H 1.5m
